GTW-2460 CNC
24” X 60” Heavy Duty CNC Lathe
- L4.09” Bar Capacity
- L24” Swing Diameter over Bedways
- L60” Between Centers
- LCompact Footprints make it ideal fo R&D and Toolroom shops
- LEasy to use Fanuc or Fagor CNC Control
- LMeehanite casting help minimize vibration for superior finish and tool life
$0.00 Down Financing
Machine Specifications
Capacity & Dimensions
|
Swing over Bed |
24″ |
(610mm) |
|
Swing over Cross Slide |
14.5″ |
(370mm) |
|
Center Height |
12″ |
(305mm) |
|
Center Distance |
59.05″ |
(1500mm) |
|
Bed Length |
102.36″ |
(2600mm) |
|
Bed Way Width |
15.75″ |
(400mm) |
|
Bed Casting Height |
13 3/8″ |
(340mm) |
Spindle
|
Spindle Motor Horsepower |
20 HP Peak |
(15 HP 30min duty) (11Kw – 15Kw) |
|
Spindle Speeds – Programmable |
30 – 1600 RPM |
infinitely variable, in 2 gear ranges |
|
Spindle Speed 2 Gear Ranges – Programmable |
M41=30 – 600 |
M42 = 80 – 1600 RPM |
|
Spindle Speed |
H = 80 – 1600 RPM |
L= 30 – 600 RPM |
|
Spindle Bore |
ø4.09″ |
(104mm) (90mm with hydraulic chuck) |
|
Spindle Nose – Camlock |
D1-8 Camlock |
75mm Draw tube |
|
Spindle Bearings – 2 bearing spindle |
Tapered Roller Bearings front, roller bearing rear |
|
|
Spindle ID taper in spindle nose |
MT-8 |
MT#8 Taper |
Cross Slide X Axis
|
Rapid Traverse Feedrate |
197 IPM |
(5m/min) |
|
X-Axis motor power |
FANUC |
Beta IS4 0.75Kw 4000RPM |
|
Cross Slide Travel |
12.63″ |
(320mm) |
|
Cross Slide Dimensions – width x length |
9.05″ x 29.9″ |
(230 x 760mm) |
|
Cross Slide Ballscrew diameter |
.984″ |
(25mm) |
|
Cross Slide Ballscrew Pitch |
5mm |
Accuracy Grade C3 (H-P Laser Tested) |
|
Cross Slide Thurst |
1190 lbs |
(540 Kg Force) |
Carriage Z Axis
|
Rapid Traverse Feedrate |
197 IPM |
(5m/min) |
|
Z-Axis Motor Power |
FANUC |
Beta IS4 0.75kw (4000rpm) |
|
Z-Axis Travel |
59.05″ |
(1500mm) |
|
Cutting Tool Height Maximum |
1″ |
(25mm) |
|
Carriage ballscrew diameter |
1.26″ |
(32mm) |
|
Carriage ballscrew pitch |
5mm |
Accuracy Grade C3 (H-P Laser Tested) |
|
Carriage Slide Thrust |
1190 lbs. |
(540 Kg Force) |
Tailstock
|
Quill Diameter |
2.95″ |
(75mm) |
|
Quill Stroke – w/ selectable 2 speed Quill Advance |
6.30″ |
(160mm) |
|
Quill Taper |
MT-5 |
Morse Taper #5 |
|
Quill Tang Drive and drift-slot for tailstock |
included |
|
|
Tailstock body set-over adjustment |
±0.4″ |
(±1mm) |
Specifications
|
Coolant Pump Motor |
1/8 HP / 13.2 gal. |
|
|
Coolant Tank Capacity |
10.5 gal. |
(40 liters) |
|
Electrical Requirements |
220 vac ±5% |
60 Hz / 75 amp service |
|
Machine Weight |
8820 lbs. |
(4000 kgs) |
|
Shipping Weight |
9260 lbs. |
(4200 kgs) |
|
Machine Dimensions ( L x W x H ) |
129″ x 75″ x 80″ |
(3260 x 1900 x 2030mm) |
|
Shipping Dimensions ( L x W x H ) |
133″ x 79″ x 86″ |
